| Standard Color | Silver-Black |
| Construction | Aluminum and heavy-duty steel |
| CPU | LGA1151 Socket for 6th Gen Intel® Core? i7/i5/i3/ Pentium®/Celeron® TDP under 35W |
| System Memory | 2 x 288-pin DDR4-2133 Long DIMM max.up to 32GB |
| Chipset | Intel® H110 |
| BIOS | AMI IEFI BIOS |
| System I/O Outlet | 1 x RS-232/422/485 (COM1) |
| 5 x RS-232 (COM2-6) |
| 1 x VGA |
| 1 x HDMI |
| 1 x DisplayPort |
| 3 x Audio (Mic/Line-in/Line-out) |
| 1 x PS/2 KB & Mouse |
| 2 x 10/100/1000Mbps Ethernet |
| 4 x USB 3.0 |
| 2 x USB 2.0 |
| 1 x VDC power input connector |
| 1 x ATX power switch |
| 1 x 8 bits DIO |
| Watchdog Timer | 1 ~ 255 levels, 1 ~ 255 sec. |
| Storage | 1 x 2.5” SATA HDD drive bay |
| 1 x Msata |
| System Indicator | 1 x green LED for system power-on |
| 1 x orange LED for HDD active |
| Power Supply input | 9~36VDC |
| Operating Temperature | -5°C ~ +45°C (HDD) ,-10°C ~ +60°C (w/ W.T RAM SSD) |
| Humidity | 10% ~ 90% |
| Dimensions | 249 mm x 200mm x 64 mm (W x D x H) |
