| CPU | Intel® Pentium® processor N4200 & Celeron® processor N3350 and J3455 onboard |
| System Memory | 1 x 204-pin DDR3L-1867 SO-DIMM, up to 8GB |
| Chipset | SoC integrated |
| BIOS | AMI |
| SSD | 1 x M.2 Key B (SATA, USB 2.0, PCIe x2 optional) in 22x42 or 30x42 |
| Watchdog Timer | 65536 levels, 1 to 65535 sec. |
| Expansion Interface | 1 x Half-size PCI Express Mini Card slot with mSATA supported |
| Battery Lithium | Lithium 3V/220 mAh |
| Power Input | 2 x 2-pin connector |
| +12V DC-in only |
| AT Auto Power On function supported |
| Power Requirements | Intel® Pentium® N4200 @ 1.1 GHz 8GB DDR3L Max RMS: +12V @1.3A |
| Intel® Celeron® N3350 @ 1.1 GHz 8GB DDR3L Max RMS: +12V @1.1A |
| Intel® Celeron® J3455 @1.5 GHz 8GB DDR3L Max RMS: +12V @1.8A |
| Dimensions | 100 x 72 mm |
| Board Thickness | 1.6 mm |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Humidity | 10% to 95% relative humidity, non-condensing |
| SATA | N/A |
| Hardware Monitoring | Detect CPU/system temperature and voltage |
| Ethernet | 2 x 10/100/1000 Mbps Ethernet with Intel® i211-AT; support Wake-on-LAN,PXE Boot ROM |
| Audio | HD Codec audio as Mic-in/Line-in/Line-out with Realtek ALC662 |
| USB | 2 x USB 2.0 |
| 2 x USB 3.0 |
| Serial | 1 x RS-232/422/485 |
| 1 x RS-232 |
| TPM | N/A |
| SMBus | Yes; compatible with I2C |
| Digital I/O | 4-channel in/out programmable |
| Display Chipset | Intel® integrated Gfx graphic engine |
| Display Memory Size | Share system memory |
| Display Interface | 1 x DisplayPort |
| 1 x LVDS; 18/24-bit single/dual channel |
